The Arne Urban floodlight elegantly integrates into any urban space, with multiple solutions that allow it to adapt to the most demanding of programs. The floodlight has a renewed appearance and improved installation, maintenance, and durability.
Products /
The Arne Urban floodlight elegantly integrates into any urban space, with multiple solutions that allow it to adapt to the most demanding of programs. The floodlight has a renewed appearance and improved installation, maintenance, and durability.
Please note: Images may depict products with optional upgrades not included as standard. Some images are architectural renders and are intended for illustrative purposes only. Actual product appearance may vary
Adjustable for column, multiple-column, indirect column, catenary or wall-mounted installation
Optional comfort accessory to control and partially block glare
Wide choice of light distributions: Wideflood, Flood, Medium, Spot, Type II-IV, Widespot symmetrical
Remote dimming via 1-10V/0-10V or DALI protocols
Anodised injected aluminium EN-AC-47100 floodlight body with powder-coated finish.
Interior ABS-PC plastic reflector and tempered optical glass diffuser.
A2 stainless steel hardware and metal cable gland.
Column-mount brackets and flanges in AISI304 stainless steel and powder-coated cast aluminium; columns made from hot-dip galvanised steel.
18 LEDs: 21W, 30W, 40W
36 LEDs: 39W, 56W, 78W
Custom Column heights
Floodlight weight: approx. 5.7kg
Service life: TM21 L90 (10k) > 100,000 h
Complies with Australian and New Zealand requirements under the Regulatory Compliance Mark (RCM), including electrical safety and EMC regulations. Certified according to applicable AS/NZS standards through recognised independent laboratories. RoHS compliant for electrical and electronic components. IP66 rated and IK08 impact rated. Class I electrical protection. Luminaires comply with AS/NZS 60598 and AS/NZS CISPR 15 requirements for safety and electromagnetic compatibility.
